SW-3 Self Propelled Thermoplastic Convex Road Marking Machine
  • :
描述

Features:


1. Fully automatic
2. Efficient marking



Specification:

Dimension (L×W×H):1380*930*1090 mm
Weight:245 kg
Paint tank capacity:100KG, 200KG or Customized
Glass beads tank capacity:10 kg
Driving speed:forward 0-6km/h back off 0-4km/h
Working voltage:6V,12V,24V
Marking width:150/200/300mm
Spreading width of glass bead dispenser:100-200mm adjustable
Marking speed:>400 m/h
Thickness of bottom line:1mm-4mm
Convex block height:3mm-10mm
Application area:blind road, dangerous area such as school entrance etc





Parts:



                 Convex Die Shoe                                                                          Control Console

Convex marking shoe: Controlled by the electromagnetic valve to mark convex lines.
Console: Powered by Simons chip to control the operation of the machine.





                          Air storage tank                                                                    Controller panel



Air storage tank: Store air and generate pressure to provide power for marking shoes.
Controller panel: Adjust the length of the block and the spacing between block rows.
