Features:
1. Diesel and natural gas can be used as fuel.
2. Suitable for long-distance marking projects.
3. Short heating time: 15-20 minutes to fully heat a can of paint.
Specification:
| Tank Quantity | Double Tanks |
| Size (L×W×H) | 1830*1740*1650 mm |
| Net Weight | 1120kg |
| Fuel | diesel oil and gas |
| Heating Temperature | 180℃-220℃ |
| Diesel Engine | 15P Electric-started water cooling diesel engine |
| Hydraulic Oil Tank Capacity | 70L |
| Thermal Insulation Layer | 4mm thickness steel plate, 5cm thickness insulation cotton and 1mm thickness stainless steel |
| Paint Tank Bottom Thickness | 6mm |
| Heating System | Liquefied petroleum gas (natural gas) and diesel, adopt energy-efficient burner (Direct injection Stove) |
| Rotating Speed of Stirring Device | 20-100r/min |
| Hydraulic System Pressure | 5 Mpa |
| Working Pressure | 4-5 Mpa |
Parts:
Stirring device Burner
Stirrer: It stirs the paint to ensure that paint in the preheater is evenly heated during the heating process going on in the pre-heater.
Stove: Heating the thermoplastic paint kettle with fuel.
Hydraulic motor Multi-way valve
Hydraulic motor: it controls the pressure of hydraulic.
Multi-way valve switch: it controls the rotation direction of stirrer.
Packing:
