Model No.:

JD200-3-35ACL

Power Consumption:

Full ball ≤ 5W

Working Voltage:

85-265VAC-50/60Hz , 12V/24VDC;

Wave length (nm):

Red:625±5;Yellow:590±5;Green:505±5

LED Q’ty:

Red-61 pcs;Yellow:-61 pcs;Green - 61 pcs

Housing Material:

PC,UV Resistant

Life Span:

>100,000 Hours.

Delivery Time:

Samples within 5days, Lot of order within 15days.

Certificates:

CE, Chinese GB14887-2003 standards, IP65.

Warranty Time:

2 years

Technical Parameters:

Color

LED Q.ty

Light Intensity

Wave Length

Viewing Angle

Power

Working Voltage

Housing Material

L/R

U/D

RED

61pcs

≥305cd

625±5nm

30°

30°

≤3W

85V-265VAC,50/60HZ; 12/24VDC

PC,UV Resistant

YELLOW

61pcs

≥305cd

590±5nm

30°

30°

≤3W

GREEN

61pcs

≥488cd

505±5nm

30°

30°

≤5W

Packing Info:

Carton Size

Q'TY

GW

NW

Wrapper

Volume(CBM)

87*33*24cm

1pcs/carton

8kg

6kg

K=K Carton

0.069

Packing List:

Part name

Light

L Bracket

Sun Visor

M4x10 Screw

M4x20 Screw

Wiring Box And Gasket

Using Manual

Certificate

Q'ty.(pcs)

1

2

3

12

4

1

1

1
